SEW Eurodrive servo geared motor KHF37R17DRN71M4BE1HF/ASB8/AK8W


SKU: KHF37R17DRN71M4BE1HF/ASB8/AK8W
Offer€1.428,00

plus VAT. plus shipping and handling

Only 1 items left
American Express Apple Pay Google Pay KlarnaMaestroMastercardPayPalShop Pay Union PayVisa

needed
Year of construction 2021
Motor rated speed 1415 rpm
Output speed 15 1/min
Total translation 96,00
Output torque 210 Nm
Operating factor SEW-FB 0.95
Type M4A
Primer/top coat 7031 blue gray (51370310)
Position plug/terminal box 0°
Cable entry/connector position X
Hollow shaft 30 mm
Version B5 flange version with hollow shaft and shrink disk
Perm. Output shear force at n=1400 0 N
Amount of lubricant 1. Gearbox 1.25 liters
Amount of lubricant 2. Gearbox 0.55 liters
Flange diameter 160 mm
Flange 160
Engine power 0.37 kW
Duty cycle S1-100%
Efficiency class IE3
Efficiency (50/75/100% Pn) 74.29 / 77.28 / 77.3%
CE mark yes
Motor voltage 230/400 V
Circuit diagram R13
Frequency 50 Hz
Rated current 1.78 / 1.02 A
Cos Phi 0.66
Thermal class 130(B)
Motor protection class IP54
Construction Regulation Europe (CE)
Mass moments of inertia (related to the drive side) 8.39 10-4 kgm2
Net weight 29.6 kg
Bremsmoment 5 Nm
Braking voltage 230 V
Brake control BG1.5
Against
Download Data Sheet
