Festo Vakuumsaugduse VADMI-95-P


SKU: VADMI-95-P
Offer€752,22

plus VAT. plus shipping and handling

Only 1 items left
American Express Apple Pay Google Pay KlarnaMaestroMastercardPayPalShop Pay Union PayVisa
Party
unused stock
Vacuum suction nozzle
VADMI-95-P
162528
GTIN 4052568131500
Nominal diameter Laval nozzle
0.95 mm
Grid dimension
18 mm
Silencer design
closed
Installation position
any
Ejector characteristic
high vacuum
Filter fineness
40 µm
Manual override
tentative
Integrated function
Electric discharge pulse valve
throttle
Electric on-off valve
Filter
check valve
Vacuum switch
Measured quantity
Relative pressure
Messprinzip
piezoresistiv
Switching element function
Closer
Switching function
Threshold comparator
Symbol
00991306
Valve function
closed
Reverse polarity protection
for all electrical connections
Display type
LED
Adjustment range hysteresis
-0.05 MPa ... -0.005 MPa
Adjustment range hysteresis
-0.5 bar ... -0.05 bar
Adjustment range hysteresis
-7.25 psi ... -0.725 psi
Setting options
You can
Switching status display
optical
Setting range threshold values
-0.09 MPa ... 0 MPa
Setting range threshold values
-0.9 bar ... 0 bar
Setting range threshold values
-13.05 psi ... 0 psi
operating pressure
0.2 MPa ... 0.8 MPa
operating pressure
2 bar ... 8 bar
operating pressure
29 psi ... 116 psi
Max. vacuum
85 %
Nominal operating pressure
0.6 MPa
Nominal operating pressure
6 bar
Nominal operating pressure
87 psi
Max. overload pressure
5 bar
Ventilation time at nominal operating pressure with ejection pulse
2.04 s
Operating voltage range DC
21.6 V ... 26.4 V
Duty cycle
100%
Switching output
PNP
Permit
RCM Mark
c UL us - Recognized (OL)
CE mark (see declaration of conformity)
according to EU EMC Directive
UKCA mark (see declaration of conformity)
to UK regulations for EMC
Operating medium
Compressed air according to ISO 8573-1:2010 [7:4:4]
Note on the operating/control medium
Oiled operation not possible
Korrosionsbeständigkeitsklasse KBK
2 - moderate corrosion stress
LABS compliance
VDMA24364-B1/B2-L
Medium temperature
0 °C ... 60 °C
Protection class
IP65
Ambient temperature
0 °C ... 50 °C
Product weight
250 g
Pressure measuring range
0 MPa ... 0.1 MPa
Pressure measuring range
0 bar ... 1 bar
Pressure measuring range
0 psi ... 14.5 psi
Electrical connection
4-pin
M8x1
Plug
Mounting type
optional:
with through hole
with internal thread
Pneumatic connection 1
G1/8
Pneumatic connection 3
Silencer integrated
Vacuum connection
G1/8
Material note
RoHS konform
Material seals
NBR
Material of collecting nozzle
Nickel-plated brass
Material filter
Well
Filter housing material
PC
Housing material
Aluminium wrought alloy
Silencer material
ON
POM
Piston material
POM
Material jet nozzle
Nickel-plated brass
Download Data Sheet
